The Tower Type Vertical Lifting Stereo Garage (Multiple Tower Multiple Entry/Exit), developed by Fujian Minjie Machinery Co., Ltd., offers an intelligent and efficient parking solution for urban areas with limited space. The design features multiple vertical lifting garages, each equipped with advanced automatic transport systems that ensure swift and safe vehicle parking and retrieval. With multiple entry and exit points, this garage system allows simultaneous access to different sections of the parking facility, greatly improving efficiency and convenience for users.

Product Details

This vertical lifting garage system operates through a fully automated intelligent removal device that moves vehicles from the entry point to the designated parking space. The system’s vertical lifting comb ensures smooth and precise vehicle transport. Additionally, the automatic U-turn feature allows the vehicle to face forward when being retrieved, making it easier for the driver to exit the garage.

With its space-efficient design, high-speed access, and smart vehicle detection, this garage is perfect for areas requiring maximum parking density with minimal ground space. It also boasts a high level of security, offering full protection for parked vehicles.

Key Features and Benefits

1. Minimal Space Requirement
Despite offering multiple entry and exit points, this garage system requires only a small footprint, making it ideal for dense urban areas or sites where maximizing space is crucial.

2. High-Performance Parking
The system provides fast, intelligent parking access with a speed range of 60 to 120 m/min. Parking and retrieval times range from 50 to 120 seconds, ensuring that drivers experience minimal wait times.

3. Secure, Fully Enclosed Design
The fully enclosed garage structure ensures maximum security for all parked vehicles, protecting them from theft, weather conditions, and external damage.

4. Multiple Vehicle Handling
The garage automatically detects the size of each vehicle, assigning SUVs and standard cars to appropriately sized parking spaces, optimizing the use of available space.

5. Frequency Conversion Technology
The system’s advanced frequency conversion speed regulation technology ensures smooth, safe, and efficient operation. It minimizes energy consumption, reduces noise, and ensures the garage runs smoothly even during peak hours.

6. Simple Operation and Low Maintenance
Operation is easy with the intuitive touchscreen and IC card system. Additionally, the system is designed with user-friendly maintenance features to ensure reliable, long-term performance with minimal upkeep.

7. Customizable Design
The garage can be designed with either a steel structure or a concrete exterior, allowing it to blend seamlessly into the surrounding architecture. This flexibility makes it suitable for a wide variety of building types and environments.

8. Comprehensive Safety Features
Multiple safety features, including emergency stop mechanisms, over-limit protection devices, and anti-clamping doors, ensure that both users and vehicles are protected at all times. Additionally, crash-proof devices, optical sensors for vehicle detection, and warning systems make operation safe and reliable.

Technical Specifications

Specification	Details
Model	Tower Type Vertical Lifting Stereo Garage (Multiple Tower Multiple Entry/Exit)
Layer Number	2 to 6 levels / 7 to 31 levels
Car Size (SUV)	5300mm × 1950mm × 2050mm
Car Size (Ordinary Car)	5300mm × 1950mm × 1550mm
Capacity Weight	≤2350kg
Drive Mode	Double chain drive
Lifting Motor Power	11-30 kW
Transverse Movement Motor Power	0.2 kW
Rotate Motor Power	2.2 kW
Power Supply	Three-phase, five-wire, 380V/50HZ
Lifting Speed	60-120 m/min
Transverse Velocity	12 m/min
Rotation Speed	2.3 r/min
Control Logic	Automatic Control of Frequency Conversion PLC
Operation Method	Touchscreen and IC card operation

Safety Devices

• Emergency Stop Device
  Quickly halts the system in case of any emergency, ensuring the safety of users and vehicles.

• Move Over Limit Protection Device
  Prevents overtravel of vehicles within the garage, maintaining system precision and preventing accidents.

• Upper and Lower Protection Devices
  Ensure safe and accurate positioning of the vehicle during parking and retrieval.

• Optoelectronic Detection Device
  Accurately measures vehicle dimensions such as length, width, and height to ensure proper parking space allocation.

• Crashproof Detection System
  Provides additional safety by preventing potential collisions between vehicles during operation.

• Warning Devices
  Alert users to system operations and any safety issues, keeping everyone informed during parking and retrieval.

• Power Failure Braking Device
  Ensures that the system remains safe and stable during power outages, preventing uncontrolled movements.

• Automatic Door Anti-Clamping Device
  Prevents accidents by stopping the door from closing if an obstruction is detected, ensuring user safety.




Product Highlights

• Multiple Tower Design with Multiple Entry/Exit: By utilizing multiple entry and exit points, the system significantly enhances efficiency, allowing simultaneous parking and retrieval of vehicles.
• Space-Saving with High Density: This system is ideal for long, narrow, or deep urban sites where maximizing parking density is critical.
• Smart Parking Management: Automatically identifies vehicle sizes and assigns parking spaces accordingly, optimizing space usage.
• High-Speed Operations: Fast entry and exit times ensure smooth traffic flow, especially in high-demand areas like commercial buildings, shopping malls, and apartment complexes.
• Enhanced Aesthetics: Customizable exterior designs make it easy to integrate the garage into the existing architectural environment, enhancing the visual appeal of the building.
• Efficient Power Usage: The energy-efficient system minimizes power consumption, making it an environmentally friendly option.
• Advanced Safety Features: Comprehensive safety measures, including crashproof systems and optoelectronic vehicle detection, provide peace of mind for both users and operators.

Placeholder for Product Images:

At Fujian Minjie Machinery Co., Ltd., we are committed to delivering top-quality parking solutions that meet the demands of modern urban environments. The Tower Type Vertical Lifting Stereo Garage (Multiple Tower Multiple Entry/Exit) exemplifies our dedication to innovation, efficiency, and security in the realm of intelligent parking systems.
