The Tower Type Vertical Lifting Stereo Garage (Multiple Tower Single Entry/Exit) by Fujian Minjie Machinery Co., Ltd. represents a cutting-edge, space-saving solution for modern parking needs. This system utilizes two or more vertical lifting garages, which are connected to a single entry and exit point. Vehicles are efficiently transported within the garage via an automatic intelligent transporter system, allowing for swift parking and retrieval. Designed for long and deep sites, this garage system maximizes parking space while minimizing the area needed for traffic passages. The smart and compact design makes it an ideal choice for urban environments seeking high-performance parking solutions.

Product Details

This advanced parking system operates by using vertical lifting mechanisms combined with automatic intelligent transporters. Vehicles are parked and retrieved from the same entrance/exit, with the transporter carrying the vehicle to its designated parking space. The system’s automatic turning device ensures that when a vehicle is retrieved, it faces forward, allowing drivers to exit the garage effortlessly. The fully enclosed design offers maximum protection for vehicles and guarantees a secure, high-speed parking experience.

Key Features and Benefits

1. Optimal Use of Space for Long and Deep Sites
This type of garage is perfectly suited for sites that are long and deep, significantly increasing the number of parking spaces while reducing the area needed for traffic lanes. This feature maximizes land use, making it an ideal choice for densely populated urban areas or commercial complexes.

2. High Performance and Energy Efficiency
With a focus on energy-saving and environmental impact reduction, this garage operates quietly and smoothly, offering fast, intelligent access. Vehicles can be parked or retrieved in as little as 50 to 120 seconds, ensuring a seamless user experience.

3. Fully Enclosed, Secure Parking
The fully enclosed garage structure provides the highest level of vehicle protection. Anti-theft measures and automated management systems keep vehicles secure, while the enclosed environment protects against external factors like weather and vandalism.

4. Intelligent Vehicle Detection and Parking Assignment
The system automatically detects vehicle size, ensuring that both large SUVs and smaller cars are efficiently assigned to appropriate parking spaces. This smart allocation system optimizes the use of available parking spots.

5. Advanced Frequency Conversion Technology
The garage uses frequency conversion speed regulation technology, allowing smooth and safe operation. With lifting speeds ranging from 60 to 120 m/min and a transverse velocity of 12 m/min, the system ensures efficient and reliable performance at all times.

6. Simple Operation and Low Maintenance
The garage is easy to operate through an intuitive touchscreen interface and IC card system. Additionally, the equipment is designed with convenient maintenance in mind, ensuring that upkeep is straightforward and cost-effective.

7. Customizable Exterior Design
The system can be built with either a steel structure or concrete exterior walls, allowing it to seamlessly blend into the surrounding architecture. Whether integrating with a main building or standing alone, this garage enhances the aesthetics of any environment.

8. Comprehensive Safety Devices
Safety is a priority with this system, which is equipped with multiple protection devices, including emergency stop mechanisms, current overload protection, crashproof systems, and an automatic door anti-clamping feature. These ensure that both vehicles and users are safe at all times.

Technical Specifications

Specification	Details
Model	Tower Type Vertical Lifting Stereo Garage (Multiple Tower Single Entry/Exit)
Layer Number	2 to 6 levels / 7 to 31 levels
Car Size (SUV)	5300mm × 1950mm × 2050mm
Car Size (Ordinary Car)	5300mm × 1950mm × 1550mm
Capacity Weight	≤2350kg
Drive Mode	Double chain drive
Lifting Motor Power	11-30 kW
Transverse Movement Motor Power	0.2 kW
Rotate Motor Power	2.2 kW
Power Supply	Three-phase, five-wire, 380V/50HZ
Lifting Speed	60-120 m/min
Transverse Velocity	12 m/min
Rotation Speed	2.3 r/min
Control Logic	Automatic Control of Frequency Conversion PLC
Operation Method	Touchscreen and IC card operation

Safety Features

• Emergency Stop Device
• Move Over Limit Protection Device
• Upper and Lower Protection Devices
• Up and Down Positioning Switch
• Chain Cover
• Current Overload Protection
• Optoelectronic Detection Device for Vehicle Dimensions
• Crashproof Detection Device
• Transverse Shift Positioning
• Warning Devices During Operation
• Power Failure Braking Device
• Automatic Door Anti-Clamping Device

Product Highlights

• Multiple Tower Efficiency: By using multiple towers within the system, this garage optimizes parking density while minimizing the need for traffic lanes.
• Automated Turntable: Ensures that when the vehicle is retrieved, it faces forward, making it easy for the driver to exit the garage.
• High-Speed Access: Parking and retrieval are completed in 50 to 120 seconds, offering an efficient solution for busy environments.
• Secure and Safe: Full enclosure and advanced safety features provide comprehensive protection for vehicles, keeping them secure and free from damage.
• Minimal Maintenance: The system is designed for easy and low-cost maintenance, reducing downtime and enhancing overall performance.
• Customizable Structure: Available in both steel and concrete exterior designs, this parking system can be tailored to suit the aesthetic needs of any building or environment.

Placeholder for Product Images:

At Fujian Minjie Machinery Co., Ltd., we are dedicated to providing innovative and reliable parking solutions that meet the growing demands of modern cities. The Tower Type Vertical Lifting Stereo Garage (Multiple Tower Single Entry/Exit) exemplifies our commitment to high-quality, efficient, and secure parking systems.
